Doepfer A-174-4 3D Joystick
The Doepfer A-174-4 is an innovative 3D Joystick featuring three axis.
It allows to control three control voltages at once (X, Y, Z). The joystick offers the classic X and Y axis, as well as a third axis (Z), the rotation of the joystick. The button on top activates a gate.
The module outputs normal and inverted CV, including offset adjustment for each inverted output. Additionally it features four quadrant outputs (Q1, Q2, Q3, Q4) with adjustable overlap. A quadrant voltage becomes positive when the joystick is positioned in the quadrant in question.
The 3D joystick allows physical control of any Eurorack module with CV inputs.
In this video, we show various patch examples where we use all three CV outputs of the Doepfer A-174-4 to control parameters of Doepfer modules (oscillators, filter and phaser), Cwejman Res-4 or SM-1.
